JOKAB CONTACT SAFETY MATS | Certified According to EN 1760-1
DESCRIPTION
ABB's Jokab Contact Safety Mat is used for safeguarding sections in hazardous areas around machines, presses, robots, and other types of active equipment. When conntected to a suitable monitoring system, stepping on the mat surface triggers a control signal to the stop circuit of the potentially hazardous motion. This fast contact occurs due to the area switch design on the inside of the mat.
- Can be connected to a safety relay, Vital or Pluto
- Very durable
- IP 67
- Slip-free surface
- UL 508 and CSA C22.2 no. 14
- Resistant to oil, greases - good 10% acid - 10% lye - resistant
- Temperature range: -10° C to +55° C
- 24V 100mA
- Connection cable - standard 10m 4 conductor
- Constructed from polyurethane black, 68 +/- Shore A
ADDITIONAL INFORMATION
| Safety Mat without Integrated Trim | Safety Mat with Integrated Trim | ||
|---|---|---|---|
| Material Number | Material Description | Material Number | Material Description |
| 2TLA858002R3800 | Safety Mat w/o trim 24"x24" | 2TLA858002R5600 | Safety Mat w trim 24"x24" |
| 2TLA858002R3900 | Safety Mat w/o trim 24"x30" | 2TLA858002R5700 | Safety Mat w trim 24"x30" |
| 2TLA858002R4000 | Safety Mat w/o trim 24"x36" | 2TLA858002R5800 | Safety Mat w trim 24"x36" |
| 2TLA858002R4100 | Safety Mat w/o trim 24"x42" | 2TLA858002R5900 | Safety Mat w trim 24"x42" |
| 2TLA858002R4200 | Safety Mat w/o trim 24"x48" | 2TLA858002R6000 | Safety Mat w trim 24"x48" |
| 2TLA858002R4300 | Safety Mat w/o trim 24"x60" | 2TLA858002R6100 | Safety Mat w trim 24"x60" |
| 2TLA858002R4400 | Safety Mat w/o trim 30"x30" | 2TLA858002R6200 | Safety Mat w trim 30"x30" |
| 2TLA858002R4500 | Safety Mat w/o trim 30"x36" | 2TLA858002R6300 | Safety Mat w trim 30"x36" |
| 2TLA858002R4600 | Safety Mat w/o trim 30"x42" | 2TLA858002R6400 | Safety Mat w trim 30"x42" |
| 2TLA858002R4700 | Safety Mat w/o trim 30"x48" | 2TLA858002R6500 | Safety Mat w trim 30"x48" |
| 2TLA858002R4800 | Safety Mat w/o trim 36"x36" | 2TLA858002R6600 | Safety Mat w trim 36"x36" |
| 2TLA858002R4900 | Safety Mat w/o trim 36"x42" | 2TLA858002R6700 | Safety Mat w trim 36"x42" |
| 2TLA858002R5000 | Safety Mat w/o trim 36"x48" | 2TLA858002R6800 | Safety Mat w trim 36"x48" |
| 2TLA858002R5100 | Safety Mat w/o trim 36"x60" | 2TLA858002R6900 | Safety Mat w trim 36"x60" |
| 2TLA858002R5200 | Safety Mat w/o trim 42"x42" | 2TLA858002R7000 | Safety Mat w trim 42"x42" |
| 2TLA858002R5300 | Safety Mat w/o trim 42"x48" | 2TLA858002R7100 | Safety Mat w trim 42"x48" |
| 2TLA858002R5400 | Safety Mat w/o trim 48"x48" | 2TLA858002R7200 | Safety Mat w trim 48"x48" |
| 2TLA858002R5500 | Safety Mat w/o trim 48"x60" | 2TLA858002R7300 | Safety Mat w trim 48"x60" |
Note: Custom non-stocked Safety Mats are available upon request.
| Material Number | Material Description |
|---|---|
| 2TLA858002R7400 | Safety Mat Trim Corner Conn. |
| 2TLA858002R7500 | Safety Mat Alum. Trim (by the inch) |
| 2TLA858002R7600 | Safety Mat Demo Sample |
