OVR NE12 ENCLOSED | SURGE PROTECTION DEVICE (SPD)| 160 kA or 320 kA per phase protection

FEATURES & BENEFITS

  • NEMA 12 enclosure
  • All mode protection (L-L/L-N/L-G/N-G)
  • Auxillary contacts for remote monitoring
  • Safety disconnect, fused
  • LED power on/fault indicator
  • Audible alarm
  • MOV technology
  • 160 kA or 320 kA per phase
  • Replaceable MOV blocks
  • Visual and audible MOV replacement indication
  • Surge counter/diagnostic LCD display (optional)
  • Count of surges 2 kA and higher with time and date
  • Visual diagnostic information

The OVR NE12 is a multistage protector with fast acting varistor (MOV) and EMI/RFI noise attenuation filter to limit overvoltage to values compatible with the sensitive equipment connected to the network. In addition to the OVR NE12, ABB recommends adding OVR DIN rail SPDs at branch panels and equipment, creating a multi-level approach to protection

Applications
The OVR NE12 is suitable for protection for all types of facilities and operations. It is designed with a NEMA type 12 enclosure, rated as type 2 SPD, requiring indoor installation on the load side of the main breaker or fuse.

  • Critical power(hospitals, data centers)
  • Communications
  • Renewable energy
  • Manufacturing
  • Water/waste water
  • Commercial

Specifications

  • Type 2 surge protective device
  • UL 1449,3rd edition listed
  • NEMA 12 enclosure
  • Three service voltages (AC):
  • 240/120Vsplit,480Vdelta,480/277V wye
  • 160 kA or 320 kA per phase protection
  • Shortcircuit current rating(SCCR):200kA
